SGM P-2 POI RGBW LED Flood Light

Description

SGM P-2 POI RGBW LED Flood Light

Main features and specification for SGM P-2 POI:

• High-performance color LED wash / flood light
• 43º, 21º and 15º native lenses
• Ideal application: building facades, landscape and trees, signage, and architectural features
• Rugged and ultra-compact construction in only 6.1kg (13.5 lbs.) / Low power consumption (170W)
• Superior optical color mixing and no color shifts
• Flicker-free operation with 100% smooth dimming performance
• 5-year warranty in corrosion class C5-M (marine)
• IP66-rated with a patented built-in dehumidifier for a maintenance free operation

Optical Data

• LED expected lifetime: 50,000 hours
• Lens: 15° / 21° / 43°
• Lightsource: 18 x high-power 10W RGBW LEDs

Photometric

• Beam angle(s): 14° (with 15° lens) / 26° (with 21° lens) / 36° (with 43° lens)
• Color temperature range: 2000K – 10000K
• CRI typical: 87
• Efficacy: 37 lm/W
• Light output all LEDs on: 8727 lm
• Light output blue: 715 lm
• Light output green: 2709 lm
• Light output red: 2526 lm
• Lux @ 10m: 853 lux
• Lux @ 3m: 9478 lux
• Lux @ 5m: 3412 lux
• Maximum Field Angle: 78 °
• Minimum Field Angle: 31 °

Physical

• Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
• Corrosion class: C5-M (ISO 12944)
• IP class: IP66
• Lens material: PE and tempered glass front
• Material: Aluminium
• Net dimensions: 334 x 223 x 105 mm
• Net dimensions inches: 13.2 x 8.8 x 4.1 inches
• Net weight: 6.1 kg (13.5 lbs)

Features for SGM P-2 POI

• Dehumidifier: Head
• Dimming: Electronic
• LED panel: 3 individually controllable segments
• Power / DMX indicator: Head
• Strobe: Ultra-high-speed strobe effects
• Tilt: 0 – 190°
• Tilt Locking System: POI Locking system with pignose bolts and angle indicator

Electrical

• AC power, max.: 90 – 305V 50/60Hz
• AC Power, nominal: 100 – 277V 50/60Hz
• Electrical Protection: Overload protection with automatic recover
• Max Inrush Current 230VAC: 75 A
• Max power consumption: 200 W
• Power factor: 0.97 PF (230 V)
• Power Supply Unit: Inbuilt IP 67 Auto-ranging electronic switch-mode
• Standby power consumption: 5 W
• Typical power consumption: 170 W

Programming and Control for SGM P-2 POI

• 16-bit control: Dimmer, Red, Green, Blue
• DMX channels: 3, 6, 9, 12, 15 or 22
• DMX modes: 10
• Protocol: CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S; USITT DMX512A; Wireless RDM; RDM ANSI E1.20
• Setting and addressing: RDM ANSI E1.20
• Wireless DMX: Lumen Radio with RDM

Connections

• DMX data in/out: 5 meter cable for DMX in and out
• Power: Power cable 5 meter with bare ends

Installation

• Mounting point: 2 M-10 locking points (suitable for one optional POI Omega bracket)
• Orientation: Any
• Rigging possibilities: Hanging / horizontal mounted
• Safety features: Bottom mount for safety wire
• Minimum distance to combutible materials: 0.3 meter (11 in).

Thermal

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 98 %
• Temperature range, Operating: -40°C to 50°C
• Temperature range, Start-up: -20°C to 50°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Included items

• POI Pignose-lock Key with magnet
• Safety instructions and installation quick guide
• 2 M-10 screws

SGM P-2 POI is a bright and powerful IP66-rated outdoor LED wash and flood light, ideally suited for small to medium size applications such as building facades, landscapes and trees, signage, and architectural features. The P-2 POI comes with different beam angles to comply with specific illumination tasks. It offers key features such as color calibration, seamless beam projection, and low power consumption. The P-2 POI luminaire comes with different beam angles to comply with specific illumination tasks.
