SGM P-1 Battery-driven LED Wash Light

Description

SGM P-1 Battery-driven LED Wash Light

Main features and specification for SGM P-1:

• Battery-driven IP65 RGBW LED light source
• 19° (with Med filter frame) native beam angle, adjustable via magnetic holographic filters
• Up to 24 hours battery operation
• DMX, RDM, and 100% wireless (power and control)
• 2000K – 10000K CTC control
• Ultra-high-speed strobe effect
• Practically maintenance-free and silent performance
• Flicker-free / Programmable scenes

Optical Data

• LED expected lifetime: 50,000 hours
• Lens: 10°
• Lightsource: 8 x high-power 12.5W RGBW LEDs

Photometric

• Beam angle(s): 10° (with 10° lens) / 19° (with Med filter frame) / 45° (with Wide filter frame)
• Color temperature range: 2000K – 10000K
• CRI typical: 80
• Efficacy: 33 lm/W
• Light output all LEDs on: 3073 lm
• Light output blue: 316 lm
• Light output green: 1018 lm
• Light output red: 544 lm
• Lux @ 10m: 514 lux
• Lux @ 3m: 5709 lux
• Lux @ 5m: 2055 lux
• Maximum Field Angle: 22 °

Physical

• Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
• IP class: IP65
• Lens material: Tempered glass front
• Material: Aluminium; PC/ASA; Plastic; Rubber; Steel
• Net dimensions: 334 x 254.6 x 119 mm
• Net dimensions inches: 13.2 x 10 x 4.7 inches
• Net weight: 5.7 kg (12.6 lbs)
• Net Weight Excluding Batteries: 5 kg
• Net Weight Excluding Batteries Lbs: 11

Features for SGM P-1

• Anti Theft Protection: Kensington Lock; Anti-Theft protection with movement sensor (Optional)
• Dehumidifier: Base / Head
• Dimming: Electronic
• Filters: Magnetic easy-fit spread angle filters and color frame
• LED panel: 2 individually controllable segments
• Strobe: Ultra-high-speed strobe effects
• Tilt: 0 – 190°

Electrical

• AC power, max.: 90 – 264V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical Protection: Overload protection with automatic recover
• Max Inrush Current: 60 A
• Max power consumption: 90 W
• Power Supply Unit: High-efficiency electronic switch-mode
• Standby power consumption: 3 W
• Typical power consumption: 70 W

Programming and Control for SGM P-1

• 16-bit control: Dimmer, Red, Green, Blue
• Cabled DMX: 5 pin XLR input/output
• DMX channels: 3, 4, 6, 9, 11 or 16
• DMX modes: 6
• Protocol: CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S; USITT DMX512A; Wireless RDM; RDM ANSI E1.20
• Setting and addressing: OLED graphical display / 4 buttons; RDM ANSI E1.20; Standalone mode
• Standalone mode: Quick Color; 3 programs with up to 24 scenes
• Wireless DMX: Lumen Radio with RDM

Connections

• DMX data in/out: IP65 XLR 5-pin connector, Female; IP65 XLR 5-pin connector, Male
• Power: Power input connector

Installation

• Mounting point: 2 quarter-turn locking points for one Omega bracket
• Orientation: Any
• Rigging possibilities: Hanging (Omega Bracket included) or ceiling/wall mount (optional)
• Safety features: Bottom mount for safety wire
• Minimum distance to combutible materials: 0.3 meter (11 in).

Thermal

• Cooling: Passive
• Humidity (max.): 98 %
• Temperature range, Battery Operating: -20°C to 50°C
• Temperature range, Battey Start-up: -20°C to 50°C
• Temperature range, Charging: 10°C to 45°C
• Temperature range, Operating: 0°C to 45°C
• Temperature range, Start-up: 0°C to 45°C
• Temperature range, Storage: -20°C to 25°C
• Thermal Protection: Automatic overtemperature protection

Included items

• 2 m power cable
• 1 Omega bracket with quater-turn fasteners
• Safety instructions and installation quick guide

Battery

• Battery capacity: Configurable up to 24 hours
• Battery capacity (typical use): 10 – 12
• Battery charge time up to 100%: 6.5 hours
• Battery charge time up to 75%: 3.5 hours
• Battery Option: YES
• Battery status: Battery level indicator
• Battery type: Lithium-Ion battery
• Durability: > 1000 cycles

SGM P-1 is a versatile RGBW wash with full wireless operation, designed to match the requirements of corporate productions, broadcast applications, wedding receptions, staging, and events. To further enhance its versatility, available unique magnetic holographic filters allow the P-1 to modify its beam angle depending on the application, while the onboard Lithium-Ion battery pack provides for extended run times without recharge, eliminating the need of cables or mains power. The P-1 is a smart, reliable, and powerful luminaire built in a compact, lightweight, and elegant assembly: an LED wash that sets a new standard for the most demanding users.
