SGM i-2 RGBW RGBW LED Wash Light

Description

SGM i-2 RGBW RGBW LED Wash Light

Main features and specification for SGM i-2 RGBW:

• High-performance IP65 RGBW light source with 69 LEDs
• 8º native beam angle
• Optional diffusers and barndoors
• DMX, RDM, and wireless control
• 2000K – 10000K CTC control
• Accurate 16bit dimming performance
• Practically maintenance-free
• Flicker-free / Programmable scenes

Optical Data

• LED expected lifetime: 50,000 hours
• Lens: 8.5°
• Lightsource: 69 LEDs total, 18 Red, 18 Green, 9 Blue, 24 White (5,700K)
• Optional honeycomb: Internal

Photometric

• Beam angle(s): 8° (with 8.5°)
• Color temperature range: 2000K – 10000K
• CRI typical: 80
• Efficacy: 44 lm/W
• Light output all LEDs on: 9908 lm
• Light output blue: 250 lm
• Light output green: 2553 lm
• Light output red: 1565 lm
• Lux @ 10m: 3179 lux
• Lux @ 3m: 35321 lux
• Lux @ 5m: 12716 lux
• Maximum Field Angle: 17 °

Physical

• Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
• IP class: IP65
• Lens material: PE and tempered glass front
• Material: Aluminium
• Net dimensions: 334 x 223 x 105 mm
• Net dimensions inches: 13.2 x 8.8 x 4.1 inches
• Net weight: 6.1 kg (13.5 lbs)

Features

• Dimming: Electronic
• Filters: 18°; 40°; 60°x10° (elliptical)
• Strobe: Ultra-high-speed strobe effects
• Tilt: 0 – 190°

Electrical

• AC power, max.: 90 – 305V 50/60Hz
• AC Power, nominal: 100 – 277V 50/60Hz
• Electrical Protection: Overload protection with automatic recover
• Max Inrush Current: 75 A
• Max power consumption: 230 W
• Power factor: 0.98 PF (230 V)
• Power Supply Unit: Inbuilt IP 67 Auto-ranging electronic switch-mode
• Standby power consumption: 5 W
• Typical power consumption: 100 W

Programming and Control

• 16-bit control: Dimmer, Red, Green, Blue
• Cabled DMX: 5 pin XLR input/output
• DMX channels: 3, 4, 6, 8, 9 or 10
• DMX modes: 8
• Protocol: USITT DMX512A; RDM ANSI E1.20
• Setting and addressing: OLED graphical display / 4 buttons; RDM ANSI E1.20; Standalone mode
• Standalone mode: Quick Color; Up to 24 programmable scenes

Connections

• DMX data in/out: IP65 XLR 5-pin cable 0.5m
• Power: Power cable 1 meter with bare ends

Installation

• Mounting point: 2 quarter-turn locking points for one Omega bracket
• Orientation: Any
• Rigging possibilities: Floor stand (included) or hanging (Omega clamps included)
• Safety features: Bottom mount for safety wire
• Minimum distance to combutible materials: 0.3 meter (11 in).

Thermal

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 98 %
• Temperature range, Operating: -40°C to 50°C
• Temperature range, Start-up: -20°C to 50°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Included items

• Mounting bracket (incl. screws)
• 1 Omega bracket with quater-turn fasteners
• Safety instructions and installation quick guide

SGM i-2 RGBW is a compact and lightweight wash luminaire generating a narrow beam of light in spot position, suitable for any application requiring high output over medium and long distances. Sharing some features of the P-2, like color calibration and seamless beam projection, the i-2 RGBW adds the benefits of a narrow and powerful beam with a very low power consumption. In the i-2 series, each individual lens is related to one R, G, B or W LED chip only.
