Chauvet Professional Maverick MK2 Wash

$3,494.90 $2,971.32

Chauvet Professional Maverick MK2 Wash is a bright, fully featured RGBW LED yoke wash lighting fixture with pixel mapping and zoom.


SKU: MAVERICKMK2WASH Categories: ,

Description

Chauvet Professional Maverick MK2 Wash

Main features and specification for Chauvet Professional Maverick MK2 Wash:

  • Fully featured RGBW LED yoke wash fixture with pixel mapping and zoom
  • 16-bit Dimming of master dimmer as well as individual colors for smooth control of fades
  • Virtual Color wheel with instantaneous access to 21 colors
  • Built in colors for quick design possibilities
  • Built in virtual gobo wheel with background colors for impressive atmospheric effects fast movement of pan, tilt, and zoom
  • Quiet operation for a wide range of installation situations
  • DMX, WDMX, S ACN, Art-Net, and Kling-Net control for full flexibility
  • 7° – 49° Zoom angle for variable beam sizes
  • True 1 compatible power input
  • Battery backup display with auto rotate depending on fixture orientation

Optical

  • Light Source: 12 LEDs (quad-color RGBW) 40 W, (2.6 A), 50,000 hours life expectancy
  • Color Temperature (range): 2800 to 10000 K
  • Beam Angle: 5° to 36°
  • Field Angle: 7° to 49°
  • Zoom Angle: 7° to 49°
  • Lumens – Source: 8,800
  • Lumens – Output: 5,900
  • Illuminance (7°): 19,000 lux @ 5 m
  • Illuminance (49°): 800 lux @ 5 m
  • PWM Frequency: 600 Hz, 1,200 Hz, 2,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects of Chauvet Professional Maverick MK2 Wash

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Strobe Rate: 0 to 20 Hz
  • Standalone Color Mixing: No
  • Color Temperature Presets: Yes
  • Move-in-Black: Yes
  • Dim Curves: 4

Construction / Physical

  • Dimensions: 12.72 x 9.17 x 18.54 in (323 x 233 x 471 mm)
  • Weight: 32.8 lb (14.8 kg)
  • Exterior Color: Black
  • Housing Material: High-impact flame-retardant polymer

Connections

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input/Output: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)

Control for Chauvet Professional Maverick MK2 Wash

  • Control Protocol: Art-Net, sACN, Kling-Net, DMX, W-DMX
  • DMX Channels Single Mode: 20, 69, 115
  • DMX Channels Dual Mode – Function: 8, 20, 26
  • DMX Channels Dual Mode – Pixel: 36, 48, 60
  • Art-Net Channels Single Mode: 20, 69, 115
  • Art-Net Channels Dual Mode – Function: 8, 20, 26
  • Art-Net Channels Dual Mode – Pixel: 36, 48, 60

Electrical

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 2 units @ 120 V; 4 units @ 208 V; 5 units @ 230 V
  • Power and Current: 651 W, 5.51 A @ 120 V, 60 Hz
  • Power and Current: 629 W, 3.03 A @ 208 V, 60 Hz
  • Power and Current: 609 W, 2.53 A @ 230 V, 50 Hz

Certifications / Qualifications

  • CE, MET
  • IP Rating: IP20, dry location

Included

  • Chauvet Professional Maverick MK2 Wash
  • Seetronic Powerkon IP65 power cord
  • Omega bracket with mounting hardware

Optional Accessories

  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Safety Cable: SC-07
  • Ethercon extension cables
  • IP rated Seetronic Powerkon extensions
  • DMX cables

Chauvet Professional Maverick MK2 Wash rewrites the rules on wash fixtures with its flawlessly even output, custom designed optics, full pixel mapping, virtual gobo wheel with background colors, pre-programmed colors and 7° – 49° zoom range. Powered by 12 (40 W) Osram RGBW LEDs, it can handle any application, even aerial washing, with ease. Take control with DMX, sACN, Art-Net, Kling-Net or W-DMX.
