Zero 88 Splitter 8

Description

Zero 88 Splitter 8

Main features and specification for Zero 88 Splitter 8:

• 1 input, 8 output DMX / RDM splitting
• Fully RDM compatible
• “Fix Switch” for data-fixing
• Opto Isolated Input
• Electrically (transient) protected outputs
• Desk Mount or 1RU 19” Form Factor
• Neutrik 5pin XLR connectors
• IEC power connector (94-230V AC)
• 3 year warranty
• CE compliant to all relevant standards

Splitter 8 provides flexible DMX / RDM data distribution in a slim (1RU) 19” format, offering both splitter and “data fix” functionality in a single device.

Zero 88 Splitter 8 is fully compatible with the latest RDM protocol, ensuring your DMX distribution network is ready to meet your future demands. Splitter 8 is appropriate for permanent installations or as a flexible, adaptable rental & touring tool.

“Fix Switch” is designed for systems where compatibility issues (or poorly designed fixtures) are causing flickering. When enabled, “Fix Switch” discards non-DMX data (including RDM) and adjusts the DMX timing to values more likely to work with fixtures that do not fully comply with the DMX standard.

The input is optically isolated, with a “Thru” connection for further expansion. The eight buffered outputs are protected against electrical faults. All connectors are Neutrik parts.

Splitter 8 is ideal for use alongside Gateway 4 and Gateway 8 to build a larger data distribution system.
