Description

Zero 88 RigSwitch

Main features and specification for Zero 88 RigSwitch:

• DMX control per circuit (or control via DALI and iCANnet)
• Remote button panels available, or use any switch via contact closure
• Intelligent propagation delay to reduce power-up inrush nuisance tripping
• Manual override of any circuit (mechanical, not digital)
• 10 or 16 amps per circuit
• Neutral Disconnect MCBs (with incoming RCD) or RCBO per circuit
• Includes cable gland plate insert (top)

RigSwitch is a remote controlled power switching solution suitable for any size venue, utilising Cooper Lighting Solutions broad portfolio of power management technologies.

RigSwitch can be delivered in 12 or 24 channel cabinet configurations with RCD or RCBO options with a choice of user control interfaces. With individual relays rated for up to 32A operation RigSwitch can cater for even the most power hungry user.

RigSwitch is ideal for switching power for today’s modern entertainment lighting systems, including moving lights, LEDs, amplifiers, specials and video equipment.

Override relays

The feed through relays provide outstanding features & performance in a truly competitive package.

Each circuit is rated for up to 32 amps and is designed to switch heavy loads of all types, including resistive, inductive & capacitive.

MCB, RCD, RCBO

Circuits are protected by neutral disconnect MCBs as standard.

Optional RCDs break the incoming supply if a fault is detected.

Upgrade circuits to RCBOs to limit inconvenience tripping to individual circuits rather than the whole unit.

Control Options

Three methods of control are available – DMX, DALI and iCAN.

These can be used exclusively, or brought together to link with a virtually limitless number of other products to build a system of any size.

User interfaces

Our user interfaces include customisable keypads and your own choice of switch.
