SGM Q-2 RGBW LED flood blind strobe

Description

SGM Q-2 RGBW LED flood blind strobe

Main features and specification for SGM Q-2:

• High-performance IP65 RGBW LED light source
• 110º wide-angle coverage / Powerful high-speed strobe
• 3 individually controllable segments
• Only 6.0kg (13.2 lbs) / Low power consumption (200W)
• 2,000K-10,000K CTC control
• Accurate 16bit dimming performance
• Practically maintenance-free
• Flicker-free / Programmable scenes

Optical Data

• LED expected lifetime: 50,000 hours
• Lens: 110° fixed
• Lightsource: 864 x RGBW SMD LEDs (5,700K)

Photometric

• Beam angle(s): 107° (with 110° lens)
• Color temperature range: 2000K – 10000K
• Efficacy: 46 lm/W
• Light output all LEDs on: 9000 lm
• Light output blue: 562 lm
• Light output green: 2250 lm
• Light output red: 1379 lm
• Lux @ 10m: 35 lux
• Lux @ 5m: 141 lux
• Maximum Field Angle: 154 °

Physical

• Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
• IP class: IP65
• Lens material: Tempered glass front
• Material: Aluminium
• Net dimensions: 334 x 223 x 105 mm
• Net dimensions inches: 13.2 x 8.8 x 4.1 inches
• Net weight: 6 kg (13.2 lbs)

Features for SGM Q-2

• Dimming: Electronic
• LED panel: 3 individually controllable segments
• Strobe: Ultra-high-speed strobe effects
• Tilt: 0 – 190°

Electrical

• AC power, max.: 90 – 305V 50/60Hz
• AC Power, nominal: 100 – 277V 50/60Hz
• Electrical Protection: Overload protection
• Max Inrush Current: 75 A
• Max power consumption: 265 W
• Power factor: 0.96 PF (230 V)
• Power Supply Unit: Inbuilt IP 67 Auto-ranging electronic switch-mode
• Standby power consumption: 5 W
• Typical power consumption: 140 W

Programming and Control for SGM Q-2

• 16-bit control: Dimmer, Red, Green, Blue
• Cabled DMX: 5 pin XLR input/output
• DMX channels: 3, 6, 9, 12, 15 or 22
• DMX modes: 6
• Protocol: USITT DMX512A; RDM ANSI E1.20
• Setting and addressing: OLED graphical display / 4 buttons; RDM ANSI E1.20; Standalone mode
• Standalone mode: Quick Color; Up to 24 programmable scenes

Connections

• DMX data in/out: IP65 XLR 5-pin cable 0.5m
• Power: Power cable 1 meter with bare ends

Installation

• Mounting point: 2 quarter-turn locking points for one Omega bracket
• Orientation: Any
• Rigging possibilities: Floor stand (included) or hanging (Omega clamps included)
• Safety features: Bottom mount for safety wire
• Minimum distance to combutible materials: 0.3 meter (11 in).

Thermal

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 98 %
• Temperature range, Operating: -40°C to 50°C
• Temperature range, Start-up: -20°C to 50°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Included items

• Mounting bracket (incl. screws)
• 1 Omega bracket with quater-turn fasteners
• Safety instructions and installation quick guide

The extremly bright SGM Q-2 is a compact and lightweight flood/blinder/strobe with fast response time, smooth color mixing with no hotspots, and individually controllable segments for pixel mapping applications. Sharing some of the key features of the larger Q-7, like factory color calibration, wide angle lighting coverage, and a powerful strobe effect, the Q-2 also includes the benefits of three-segment pixel mapping control and low power consumption. Because of its rich feature set, powerful output, efficiency, small size, and easy rigging options, the Q-2 is a must-have flood/blinder/strobe for any rental company, touring production, or corporate event.
