Description
SGM P-5 POI RGBW LED Flood Light
Main features and specification for SGM P-5 POI:
- High-performance RGBW LED wash / flood light with 20031 lumen
- 43º, 21º, and 15º native lenses
- Ideal application: Medium throws for building facades and structures, bridges, and towers
- Superior optical color mixing and no color shifts at short and long distances
- Flicker-free operation with 100% smooth dimming performance
- IP66-rated with a patented built-in dehumidifier for a maintenance free operation
- 5-year warranty in corrosion class C5-M (marine)
- Rugged construction in an ultra-compact design
Optical Data
- LED expected lifetime: 50,000 hours
- Lens: 15° / 21° / 43°
- Lightsource: 44 x high-power 10W RGBW LEDs
Photometric
- Beam angle(s): 14° (with 15° lens) / 26° (with 21° lens) / 35° (with 43° lens)
- Color temperature range: 2000K – 10000K
- CRI typical: 86
- Efficacy: 44 lm/W
- Light output all LEDs on: 20031 lm
- Light output blue: 1353 lm
- Light output green: 5806 lm
- Light output red: 4725 lm
- Lux @ 10m: 1993 lux
- Lux @ 3m: 22142 lux
- Lux @ 5m: 7971 lux
- Maximum Field Angle: 76 °
- Minimum Field Angle: 30 °
Physical
- Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
- Corrosion class: C5-M (ISO 12944)
- IP class: IP66
- Lens material: PE and tempered glass front
- Material: Aluminium
- Net dimensions: 497 x 268 x 122 mm
- Net dimensions inches: 19.6 x 10.6 x 4.8 inches
- Net weight: 8.9 kg (19.6 lbs)
Features for SGM P-5 POI
- Dehumidifier: Base / Head
- Dimming: Electronic
- Power / DMX indicator: Base
- Strobe: Ultra-high-speed strobe effects
- Tilt: 0 – 190°
- Tilt Locking System: POI Locking system with pignose bolts and angle indicator
Electrical
- AC power, max.: 190 – 264V 50/60Hz
- AC Power, nominal: 208 – 240V 50/60Hz
- Electrical Protection: Overload protection
- Max Inrush Current: 45 A
- Max power consumption: 450 W
- Power factor: 0.99 PF (230 V)
- Power Supply Unit: Auto-ranging electronic switch-mode
- Standby power consumption: 8 W
- Typical power consumption: 420 W
Programming and Control
- 16-bit control: Dimmer, Red, Green, Blue
- DMX channels: 3, 4, 6, 8, 9 or 10
- DMX modes: 7
- Protocol: USITT DMX512A; RDM ANSI E1.20
- Setting and addressing: RDM ANSI E1.20
Connections
- DMX data in/out: 5 meter cable for DMX in and out
- Power: Power cable 5 meter with bare ends
Installation
- Mounting point: 2 x 2 M-10 locking points (suitable for one or two optional POI Omega brackets)
- Orientation: Any
- Rigging possibilities: Hanging / horizontal mounted
- Safety features: Bottom mount for safety wire
- Minimum distance to combutible materials: 0.3 meter (11 in).
Thermal
- Cooling: Active, Forced Air, Temperature-regulated
- Humidity (max.): 98 %
- Temperature range, Operating: -40°C to 50°C
- Temperature range, Start-up: -20°C to 50°C
- Temperature range, Storage: -40°C to 80°C
- Thermal Protection: Automatic overtemperature protection
Included items
- POI Pignose-lock Key with magnet
- Safety instructions and installation quick guide
- 4 M-10 screws
SGM P-5 POI is a powerful IP66-rated outdoor RGBW LED wash and flood light with a bright and accurate beam projection, suitable for any architectural application that requires high output over long distances, thus, perfect for medium to large-scale applications such as building facades and structures, bridges, and towers. The P-5 POI luminaire comes with different beam angles to comply with specific illumination tasks.
Did not find what you need? Send us an enquiry
_______________________________
Glossary: SGM P·5 POI, SGM P5 POI, SGM P 5 POI
| Brand | |
|---|---|
| Select Fixture Option | P-5 Wash, 43deg, POI, BL, P-5 Wash, 21deg, POI, BL, P-5 Wash, 15deg, POI, BL, P-5 Wash, 43deg, POI, WH, P-5 Wash, 21deg, POI, WH, P-5 Wash, 15deg, POI, WH, P-5 Wash, 43deg, POI, CU, P-5 Wash, 21deg, POI, CU, P-5 Wash 15deg, POI, CU |
