SGM G-1 Wash POI RGBW LED Projector

Description

SGM G-1 Wash POI RGBW LED Projector

Main features and specification for SGM G-1 Wash POI:

• Full ‘moving head’ functionality with continuous pan and 240° tilt
• The high output makes it suitable for small to medium sized applications such as entrance features, signage, and landscaping
• Ideal for coastal and offshore installations such as beach bars and cruise
• RGBW / no hotspots / ultra-smooth movement / flicker-free / programmable scenes
• Fully RDM compatible making es it suitable for non-accessible locations
• IP66-rating and corrosion class C5-M (marine) for a practically maintenance-free operation
• 5-year warranty
• Cabled DMX with full RDM protocol

Optical Data

• LED expected lifetime: 50,000 hours
• Lens: 8.5°
• Lens angle: 8.5 °
• Lightsource: 19 LEDs total, 4 Red, 4 Green, 4 Blue, 7 White (5.700K)

Photometric

• Color temperature range: 2000K – 10000K
• Efficacy: 38 lm/W
• Lux @ 10m: 549 lux
• Lux @ 3m: 5078 lux
• Lux @ 5m: 2194 lux

Physical

• Color options: Black – RAL 9004; Custom color – Any RAL; White – RAL 9010
• Corrosion class: C5-M (ISO 12944)
• IP class: IP66
• Material: Aluminium; PC/ASA; Plastic; Rubber; Steel
• Net dimensions: 219 x 382 x 255 mm
• Net dimensions inches: 8.6 x 15.1 x 10 inches
• Net weight: 7.7 kg (17 lbs)

Features

• Built-in macro effects: 50 macros
• Dehumidifier: Head
• Dimming: Electronic
• Pan: Endless
• Pan modes: 360°; 360° Shortest path; 540°; Continues CCW; Continues CW; Endless
• Power / DMX indicator: Head
• Strobe: Ultra-high-speed strobe effects
• Tilt: 240°

Electrical

• AC power, max.: 90 – 264V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• DC power, nominal: 24 VDC
• Electrical Protection: Overload protection with automatic recover
• Max Inrush Current 230VAC: 35 A
• Power Supply Unit: Auto-ranging electronic switch-mode
• Standby power consumption: 7 W
• Typical power consumption: 40 W

Programming and Control

• 16-bit control: Dimmer, pan and tilt
• DMX channels: 13
• DMX modes: 1
• Protocol: USITT DMX512A; RDM ANSI E1.20
• Setting and addressing: RDM ANSI E1.20

Connections

• DMX data in/out: 5 meter cable for DMX in and out
• Power: Power cable 5 meter with bare ends

Installation

• Mounting point: 2 M-10 locking points (suitable for one optional POI Omega bracket)
• Orientation: Any
• Rigging possibilities: Hanging / horizontal mounted or ceiling / wall mount (optional)
• Safety features: 2 attachment points for safety wire
• Minimum distance to combutible materials: 0.3 meter (11 in).

Thermal

• Cooling: Passive
• Humidity (max.): 98 %
• Temperature range, Operating: -40°C to 50°C
• Temperature range, Start-up: -20°C to 50°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Included items

• Safety instructions and installation quick guide
• 2 M-10 screws

Battery

• Battery Option: YES

SGM G-1 Wash POI is the ideal companion for the G-1 Beam POI and perfect for any type of permanent outdoor installation as well as smaller outdoor venues in need of a small moving wash light with high output, uniform colors from a distance, and color calibration to match other SGM fixtures. Despite its small footprint and low power consumption, the optical system provides a remarkable output, delivering staggering brightness and accurate color temperature control with a completely even field and no hotspots.
